Component Inspection





P0201 Injector Circuit/Open-Cylinder 1

Inspection/Repair - Component Inspection

Component Inspection

1. IG OFF.
2. Disconnect the Injector connector.
3. Measure the resistance of the Injector.
Specification :









4. Is the measured resistance within specifications?
