Scantool Diagnostics

P0713 Transmission Fluid Temperature Sensor \'A\' Circuit High Input

Scantool Diagnostics

Monitor GDS Data

1. Connect GDS to Data Link Connector (DLC).
2. Ignition "ON" & Engine "ON".
3. Select "Current Data" mode and monitor "Oil temperature sensor" parameter.

Specification : Increasing Gradually








Fig 1) Normal Data
Fig 2) Open Data
4. Is the Oil temperature sensor within specification?
