Component Inspection

P0532 A/C Refrigerant Pressure Sensor A Circuit Low Input

Inspection/Repair - Component Inspection

Component Inspection

1. A/C pressure sensor inspection
(1) Key "OFF" and connect the scantool.
(2) Connect the probe to A/C pressure sensor signal and select the oscilloscope in the menu.
(3) Check the change of waveform with A/C "ON" and "OFF" after engine start.
A. Specification :









(4) Is the measured waveform of A/C pressure sensor normal?
YES
1) Substitute with a known - good PCM and check for proper operation. If the problem is corrected, replace PCM and go to "Verification of Vehicle Repair" procedure.

CAUTION:
There is a memory reset function on scantool that can erase optional parts automatically detected and memorized by PCM.
Before or after testing PCM on the vehicle, use this function to reuse the PCM on the others

NO
1) Substitute with a known - good A/C pressure sensor and check for proper operation. If the problem is corrected, replace A/C pressure sensor and go to "Verification of Vehicle Repair" procedure.
