Monitor DTC Status

C1102 Battery Voltage Low

Scantool Diagnostics

Monitor Scantool Data

1. Connect scantool to Data Link Connector (DLC)
2. Engine "ON".
3. Monitor the "BATTERY VOLTAGE" parameter on the scantool.

Specification :Above. 9±0.5 V




Fig 1) Test Condition : Ignition "ON" & Engine "ON".
Normal Data
4. Is parameter displayed within specifications?
