Component Inspection

P0274 Cylinder 5 Injector Circuit High

Inspection/Repair - Component Inspection

Component Inspection

Check injector
1. IG "OFF" and disconnect injector connector.
2. Measure resistance between power and control terminals of injector connector. (Component side)

Specification :13.8 - 15.2 Ohms (at 20°C/ 68°F)





3. Is the measured resistance within specification?
