Center Facia Panel Replacement

REPLACEMENT

CENTER FACIA PANEL REPLACEMENT
1. After disconnecting the connector (A), remove the center facia panel (B).

NOTE:
- When prying with a flat-up screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage.
- Put on gloves to protect your hands.




2. Installation is the reverse of removal.

NOTE:
- Make sure the connector is plugged in properly.
