Trunk / Liftgate Handle: Service and Repair

REPLACEMENT

OUTSIDE HANDLE REPLACEMENT
1. Remove the tailgate trim.
2. Remove the tailgate garnish.
3. After loosening the mounting screws, then remove the outside handle (A).




4. Installation is the reverse of removal.

NOTE:
Make sure the tailgate opens properly and locks securely.
