Home >> Kia >> 2008 >> Magentis (CANADA) L4-2.4L >> Repair and Diagnosis >> Specifications >> Electrical Specifications >> Air Flow Meter/Sensor

Air Flow Meter/Sensor

MASS AIR FLOW SENSOR (MAFS)

- Type : Hot film type
- Specification
