Clutch Pedal Assembly: Testing and Inspection

INSPECTION
1. Check the pedal shaft and bushing for wear.
2. Check the clutch pedal for bending or torsion.
3. Check the return spring for damage or deterioration.
4. Check the pedal pad for damage or wear.

IGNITION LOCK SWITCH INSPECTION








Remove the ignition lock switch and check for continuity between the terminals. If the continuity is not as specified, replace the switch.

RETURING TEST OF CLUTCH PEDAL
Deformation of pedal pad must be MAX. 5mm after repeating the test 20 times (sudden return from full stroke).
