Rear Bumper: Service and Repair

Removal
1. Remove trunk end trim. Refer to "Trim".
2. Remove trunk corner trim. Refer to "Trim".
3. Remove rear combination light assembly. Refer to "Exterior lights".
4. Remove three nuts from right side of the bumper.




5. Repeat for left side.
6. Remove two bolts from left rear bumper stay.




7. Repeat for right side.
8. Remove rear bumper.

Installation
Install in reverse order of removal.

Tighten rear bumper mounting bolts to 23 - 28 lb.ft (31 - 38 N.m, 3.2 - 3.9 kg.m)
