Removal

1. Disconnect negative battery cable.
2. Remove door trim. Refer to "Trim".




3. Remove one screw on pull handle bracket.
4. Remove pull handle bracket.
5. Remove speaker.




a. Remove three screws on door speaker.
b. Unfasten harness connector from door frame.
c. Pull out speaker and disconnect connectors


NOTE: Peel plastic moisture barrier off carefully so that it can be reused.




6. Peel off plastic moisture barrier carefully by pulling it away gradually from door frame.
7. Disconnect outside door handle rod of door lock assembly from outside door handle.
8. Disconnect lock cylinder rod of door lock assembly from door lock cylinder of door handle.
9. Remove two mounting bolts on outside door handle.
10. Remove outside door handle.
11. Remove lock cylinder retainer from outside door handle.




12. Remove lock cylinder from outside door handle.
