Home >> Kia >> 1997 >> Sephia LS Sedan L4-1.8L >> Repair and Diagnosis >> Sensors and Switches >> Sensors and Switches - Instrument Panel >> Door Switch >> Testing and Inspection >> Door Jamb Switch >> Switch Testing

Switch Testing




Confirm for continuity between the terminals of the door jamb switch.
