B1424

B1424-IMPROPER DVD-WRONG REGION

For a complete wiring diagram, Refer to the Wiring Information.

- When Monitored:
Continuously with the ignition on and the DVD player turned on.

- Set Condition:
The code will set if a DVD that is not formatted as a DVD is installed in the DVD player.





DVD PLAYER
1. Replace the problem DVD with a good, clean, unscratched DVD.
2. Turn the DVD player on.
3. With the scan tool, read DTC's.

Does the scan tool display active: B1424-IMPROPER DVD-WRONG REGION?

Yes

- Eject the inoperative DVD and replace the DVD.
- Perform the BODY VERIFICATION TEST. Body Verification Test

No

- Test Complete.
