U0195

U0195-LOST COMMUNICATION WITH SDARS

For a complete wiring diagram, refer to the Wiring Information Electrical Diagrams..

- When Monitored:
Continuously when the ignition is on.

The battery voltage is between 10 and 16 volts.

IOD fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

- Set Condition:
Bus messages not received from the Satellite Receiver (SDAR) for approximately two to five seconds.





VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE

NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding.

1. Turn the ignition on.
2. With the scan tool, read the active DTCs.

Is this DTC active?

Yes

- Perform the diagnostic procedure for this DTC. Testing and Inspection.

No

- Perform the Stored Lost Communication DTCs diagnostic test procedure. Stored Lost Communication DTCs.
