B2255

B2255-OCCUPANT RESTRAINT CONTROLLER ROLL OVER FEATURE DISABLE

- When Monitored:
With the ignition on. The module's on board diagnostics continuously performs internal circuit tests.

- Set Condition:
This DTC will set if the ORC Roll Over Feature has been disabled via the scan tool.





OCCUPANT RESTRAINT CONTROLLER ROLL OVER FEATURE DISABLED
1. Turn the ignition on.
2. With the scan tool read the ORC Roll Over Feature status Enabled or Disabled.

Does the scan tool show Roll Over Feature Disabled?

Repair

- With the scan tool select Enable to clear the active B2255 DTC.
- Perform the *AIRBAG SYSTEM VERIFICATION TEST - VER 1. Airbag System Verification Test
