Rear

REMOVAL





1. Raise and support the vehicle.
2. Remove the wheel speed sensor mounting bolt (2) from the rear support plate (1).










3. Remove the wheel speed sensor (3) from the support plate.
4. Disconnect the wheel speed sensor electrical connector (3).
