Brake Master Cylinder Reservoir - Removal

REMOVAL










1. Install a brake pedal prop rod.
2. Remove reservoir cap and remove fluid with a clean suction gun.
3. Remove the wire connector from the brake fluid level sensor (2).










4. Remove the fluid reservoir (1) from the master cylinder (3).










5. Pull the reservoir straight up out of the cylinder (2).
6. Remove and discard grommets from the cylinder body (2).










7. Remove the fluid level sensor (1) from the reservoir (2) if needed.
