Rear

REAR

1. Raise and support vehicle.
2. Remove rear wheel and tire assembly.
3. Drain small amount of fluid from master cylinder brake reservoir with a clean suction gun.









4. Bottom caliper pistons into the caliper by prying the caliper over.
5. Remove the caliper slide pins (4).










6. Remove caliper (1) from the anchor.
7. Secure caliper (1) to nearby suspension part with wire. Do not allow brake hose to support caliper weight.
8. Remove the inboard AND outboard brake pads from the caliper.
