Front Side Marker Lamp

Removal

1. Turn the steering to full lock, as follows:
Right-hand marker - Left-hand lock.
Left-hand marker - Right-hand lock.





2. Remove the access panel from the wheel arch liner.
1. Release the center fastener which secures the wheel arch liner access panel.
2. Lift the lower retaining catch and disconnect the lower edge of the access panel from the wheel arch liner.
3. Remove the access panel.





3. Remove the marker lamp.
1. Disconnect the connector from the rear of the lamp.
2. Compress one of the retaining spring clips and remove the lamp.


Installation
1. Installation is the reverse of removal.
Return steering to straight ahead position.
