Engine Compartment

Two forward bulkhead extensions are located against the main engine compartment bulkhead and fenders. The left-hand compartment carries the brake booster and master cylinder and relays. The other compartment carries the ECM, TCM, relays, fusebox and a cooling fan. Air for cooling the compartment is taken from, and returned to the cabin by ducting.

At the front left side of the engine compartment are located the windshield/headlamp wash reservoir filler, the power steering oil reservoir, left front fusebox and the brake control module.

An electric motor driven water pump and valve are located centrally against the bulkhead. The valve is located behind a heat shield and below the coolant reservoir/header tank.
