M3: Air Intake System Check







Check air intake system

Air cleaner free from obstruction?
Air meter to throttle body seal OK?
Engine breather to Inlet duct OK?
Throttle body to engine free of air leaks?
Vacuum system OK?


Yes
Go to M4

No
Rectify the fault(s) and test the system for normal operation
