E6: Check For Short to B+

Measure the voltage between EM013/019 & EM013/027

0 volts?

Yes
Go to E7

No
Inspect EM013 & PI017 for corrosion, bent / pushed back pins or locate & repair the harness / connector PI001 Test the system for normal operation
