Rear Quarter Casings

The rear quarter casings are individually styled to suit installation in either the coupe or convertible.

Both styles are trimmed in ambla and incorporate acoustic cloth-covered speakers. Coupe casings are additionally fitted with ambla-trimmed armrests and stowage trays.

Convertible rear quarter casings are secured at the rear by dowels locating in the seat squab panel, and at the front by spring steel clips locating in the "B" posts. Coupe rear quarter casings are retained by spring steel clips located in the cantrails and "B" posts and a screw passed through each front seat belt escutcheon. A plastic clip in each coupe rear quarter engages in the parcel shelf.
