Adjustable Rear Seat

Rear Seat Heater Switch Assembly-Adjustable Rear:

On vehicles fitted with adjustable rear seats the heater control switches are installed on the rear console (Fig.1).
The switches are two position rocker switches with a status indicator.
To renew the switch assembly, lift the centre armrest, remove the stowage box, disconnect multi-plug and undo and remove fixings.
