Removal and Installation Without 4WAS

POWER STEERING CONTROL UNIT

Removal and Installation


REMOVAL

1.Remove glove box assembly. Exploded View A/T Models(A/T models), {LINK_TO:0000000007473103}, "M/T
MODELS : Exploded View"(M/T models).





2.Remove power steering control unit screws.
3.Remove power steering control unit (1).
4.Disconnect power steering control unit connector.

INSTALLATION

Install in the reverse order of removal.
