Inlet Port Memory Function

INSPECTION AND ADJUSTMENT


Inlet Port Memory Function


DESCRIPTION
When ignition switch is turned from OFF to ON, inlet port can be set to AUTO or manual.

Operating procedures for this trimmer are as per the following:
1. Begin self-diagnosis STEP-5 mode. Scan Tool Testing and Procedures.
2. Press fan (UP:+) switch to set system in auxiliary mode.
3. Press intake switch as desired.
