19.
A/T Does Not Shift: 2[2] -> 1[1], When Selector Lever "2" -> "1" Position
SYMPTOM: A/T does not shift from 2[2] to 1[1] when changing selector lever from "2" to "1" position.
Part 1 of 2
Part 2 of 2
