13.
A/T Does Not Hold Lock-up Condition
SYMPTOM: A/T does not hold lock-up condition for more than 30 seconds.
Part 1 of 5
Part 2 of 5
Part 3 of 5
Part 4 of 5
Part 5 of 5
