Axle Nut

Axle Nut

Remove the split pin(A), then remove castle nut(B) and washer(C) from the front hub under applying the break.

Tightening torque N.m (kgf.m, lb-ft) 200 - 280 (20.0 - 28.0, 144.6 - 202.5)






CAUTION:
The washer (B) should be assembled with convex surface outward when installing the castle nut (A) and split pin (C).
