Diode: Locations

A/C Wiring Harness.:

Left Rear Corner Of Engine Compartment Along Left Inner Fender

Applicable to: 1987

A/C Wiring Harness.:

RH Side Behind Glove Compartment

Applicable to: 1987

A/C Wiring Harness (Part 1 Of 2).:

A/C Wiring Harness (Part 1 Of 2).:

Left Rear Corner Of Engine Compartment

Applicable to: 1988 Less Factory Installed System

A/C & Lock Up Wiring Harness (Part 1 Of 2).:

A/C & Lock Up Wiring Harness (Part 1 Of 2).:

Left Rear Corner Of Engine Compartment

Applicable to: 1988 w/Factory Installed System

A/C Wiring Harness (Part 1 Of 2).:

A/C Wiring Harness (Part 1 Of 2).:

RH Side Under Dash

Applicable to: 1988 Less Factory Installed System

A/C & Lock Up Wiring Harness (Part 1 Of 2).:

A/C & Lock Up Wiring Harness (Part 1 Of 2).:

RH Side Under Dash

Applicable to: 1988 w/Factory Installed System
