C0563
DTC C0563
Circuit Description
On the power-up self test, the calibration data stored in the electronically erasable programmable read-only memory (EEPROM) is copied to shadow RAM. Data checksums are generated and verified, and the data in shadow RAM is verified against the contents of the EEPROM. In certain situations data is written to the EEPROM. In these circumstanced any checksums are recalculated, and the data written to the EEPROM is read back and compared with the original data.
DTC Descriptor
This diagnostic procedure supports the following DTC:
DTC C0563 Calibration Read-Only Memory (ROM) Checksum Error
Conditions for Running the DTC
The ignition is ON.
Conditions for Setting the DTC
If the EEPROM test fails then it is repeated. If the fault is still present after 5 test cycles, then a DTC is set.
Action Taken When the DTC Sets
* Air Suspension functionality is suspended.
* SERVICE AIR SUSPENSION message is displayed.
Conditions for Clearing the DTC
DTC is cleared by cycling ignition.
