Oil Separator: Service and Repair

Oil/Air Separator Installation
1. Remove all of the old liquid gasket from the oil/air separator mating surfaces, bolts, and bolt holes.
2. Clean, and dry the oil/air separator mating surfaces.





3. Apply liquid gasket, P/N 08717-0004, 08718-0001, 08718-0002, 08718-0003, or 08718-0009, evenly to the engine block mating surface of the oil/air separator.

NOTE: Do not install components if too much time has passed after applying the liquid gasket (for P/N 08718-0002, no more then 4 minutes, for all others, no more than 5 minutes). Instead, remove the old residue and reapply the liquid gasket.





4. Install the oil/air separator.

NOTE:
^ Wait at least 30 minutes before filling the engine with oil.
^ Do not run the engine for at least 3 hours after installing the oil/air separator.
