Instruments - Ignition Switch Binds: Overview

97-012

BODY

MAR 3, 1997

Applies To:
1996 Civic - ALL
1997 Civic - 2-door thru VIN 1HGEJ... .VL022710
- 3-door thru VIN 2HGEJ... .VH104923
- 4-door thru VIN 1HGEJ... .VL008977
thru VIN 2HGEJ... .VH523683

Ignition Switch Binds

PROBLEM
The ignition key/switch binds or is hard to turn. Occasionally, it does not return all the way to the ON (II) position from START (III).

CORRECTIVE ACTION
Replace the ignition switch.





WARRANTY CLAIM INFORMATION

In warranty:
The normal warranty applies.

Failed part:
Manual Trans P/N 35100-S01-A01
H/C 4811055
Automatic Trans P/N 35100-S01-A11
H/C 4811063

Defect code: 030
Contention code: B01

Out of warranty:
Any repair performed after warranty expiration may be eligible for goodwill consideration by the District Service Manager or your Zone Office. You must request consideration, and get a decision, before starting work.

PARTS INFORMATION

Steering lock assembly:
Manual Trans P/N 35100-501-A01, H/C 4811055
Automatic Trans P/N 35100-501-All, H/C 4811063
