Electronic Brake Control Module: Service and Repair

Fig. 87 Control Unit Replacement:

Refer to Fig. 87 when replacing the control unit.

1. Remove right quarter trim panel.
2. Remove control unit mounting bolts, then the remove control unit. When control unit mounting bolts are removed, the control unit's memory is cleared.
3. Reverse procedure to install.
