Removal

3.0L DIESEL










1. Raise and support the vehicle.
2. Remove the muffler/tailpipe assembly (7) to diesel particulate filter clamp (6).
3. Remove muffler/tailpipe assembly (7) from the isolators (4).
4. Remove muffler/tailpipe assembly (7) from diesel particulate filter (8).
5. Remove muffler/tailpipe assembly (7) from vehicle.
