Steering Control Module (SCM)

9352-STEERING ANGLE SENSOR IMPLAUSIBLE RATE OF CHANGE

For a complete wiring diagram, Refer to the Wiring Information Electrical Diagrams.

- When Monitored:
Continuously.

- Set Condition:
The Steering Column Module (SCM) has detected that the Steering Angle Sensor rotational speed has exceeded 3000 degrees per second.





DTC IS ACTIVE

NOTE: If a BATTERY VOLTAGE LOW or BATTERY VOLTAGE HIGH DTC is set along with this DTC, diagnose the battery voltage DTC first.

1. Ignition on, engine not running.
2. Turn the steering wheel from stop to stop at least three times.
3. With the Scan Tool, select View DTCs in the Steering Column Module.

Is the status for this DTC Active at this time?

Yes

- Replace the Steering Column Module (SCM).
- Perform the BODY VERIFICATION TEST. Verification Tests.

No

- The condition that caused this symptom is currently not present. Check for an intermittent condition by inspecting the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also, inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Repair as necessary.
- Perform the BODY VERIFICATION TEST. Verification Tests.
