Occupant Restraint Controller (ORC)

9014-DRIVERS SEAT BELT SENSE CIRCUIT PERFORMANCE





For a complete wiring diagram Refer to the Wiring Information Electrical Diagrams.

- When Monitored:
With the ignition on.

- Set Condition:
This code occurs only in combination with other active DTC's.





Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Restraints System Pre-Diagnostic Procedure.
VERIFY OTHER ACTIVE DTC

NOTE: Ensure the battery is fully charged.

1. Turn the ignition on.
2. With the scan tool, perform a ORC reset.
3. With the scan tool, read the active ORC DTC.

Does the scan tool display any other Driver Seat Belt Switch active DTCs?

Yes

- Diagnose and repair the DTC's.

No

- Replace the Occupant Restraint Controller (ORC).
- Perform *RESTRAINT VERIFICATION TEST Verification Tests
