D200

D200-FACE PLATE BUTTON STUCK-RADIO

For a complete wiring diagram, Refer to the Wiring Information Electrical Diagrams.

- When Monitored:
Whenever the module is awake.

- Set Condition:
When the Radio detects a stuck button for more than 30 seconds.





TEST FOR INTERMITTENT CONDITION
1. Turn the ignition on.
2. With the scan tool, record and erase DTC's.
3. Turn the radio on.
4. Wait 30 seconds.
5. With the scan tool, read DTC's.

Does the scan tool display D200-FACE PLATE BUTTON STUCK-RADIO?

Yes

- Repair or replace the stuck button as necessary.
- Perform BODY VERIFICATION TEST. Verification Tests.

No

- The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
- Perform BODY VERIFICATION TEST. Verification Tests.
