Rear Door Has Not Unlocked

980A-REAR DOOR HAS NOT UNLOCKED

For a complete wiring diagram, Refer to the Wiring Information Electrical Diagrams.

Theory of Operation

When the PSM receives a command to perform a special function, it looks at all the variable conditions that must be right. If any one of those necessary conditions are not right, it will not perform that function and will report a DTC to explain why it could not.

- When Monitored:
Continuously with ignition on.

- Set Condition:
If the Programmable Special Module (PSM) receives this information from the BCM when it is commanded to perform a function that depends on the Rear Door being unlocked, this code will set.





TEST FOR INTERMITTENT CONDITION
1. Turn the ignition on.
2. With the scan tool, record and erase the DTCs.
3. Close all doors.
4. Operate the door lock switch in both directions a few times.
5. Turn the ignition off.
6. Wait 30 seconds.
7. Turn the ignition on.
8. With the scan tool, read the DTCs.

Are there any Door Lock related DTCs active?

Yes

- Perform the appropriate diagnostic procedure(s). Testing and Inspection.

No

- Examine the door latch for any obstructions that may have caused an intermittent condition. Repair as necessary.
- Perform the BODY VERIFICATION TEST. Verification Tests.
