Front

FRONT





The front washer nozzles (1) are constructed entirely of molded plastic. The nozzles have integral mounts with snap features that secure them near the tops of the two wiper arms on the windshield. One side of the washer nozzle has an integral barbed nipple (2) that connects it to the washer supply hose. Three nozzle orifices (3) are oriented to dispense the washer fluid onto the windshield glass throughout the wiped area of the glass.

The front washer nozzles cannot be adjusted or repaired and, if ineffective or damaged, they must be replaced.
