Starter Motor: Diagrams

Component ID: 583
Component : STARTER

Connector:
Name : STARTER C1
Color :
# of pins : 3




Pin Circuit Description
1 36 1RD -
2 3877 1RD -
3 439 1RD -



Connector:
Name : STARTER C2
Color :
# of pins : 1




50 5322 12VT -
50 3915 12VT -
