Lamp-Ceiling 6
Component ID: 244
Component : LAMP-CEILING 6
Connector:
Name : LAMP-CEILING 6
Color :
# of pins : 2
Pin Circuit Description
1 U41 18RD INTERIOR LAMP TERM.30
2 U1036 18BR/DB GROUND
Component ID: 244
Component : LAMP-CEILING 6
Connector:
Name : LAMP-CEILING 6
Color :
# of pins : 2
Pin Circuit Description
1 U41 18RD INTERIOR LAMP TERM.30
2 U1036 18BR/DB GROUND
