Actuator-Recirculation Door

Component ID: 8
Component : ACTUATOR-RECIRCULATION DOOR

Connector:
Name : ACTUATOR-RECIRCULATION DOOR
Color : GRAY
# of pins : 2




Pin Circuit Description
1 2394 20DG OUTSIDE AIR/RECIRCULATED AIR FLAP CONTROL MOTOR
Pin Circuit Description
1 2391 20DG OUTSIDE AIR/RECIRCULATED AIR FLAP CONTROL MOTOR
2 2393 20OR OUTSIDE AIR/RECIRCULATED AIR FLAP CONTROL MOTOR
2 2392 20OR OUTSIDE AIR/RECIRCULATED AIR FLAP CONTROL MOTOR
