Actuator-Mode Door

Component ID: 7
Component : ACTUATOR-MODE DOOR

Connector:
Name : ACTUATOR-MODE DOOR
Color :
# of pins : 5




Pin Circuit Description
1 2404 20BR/BK POTENTIOMETER-AIR DISTRIBUTION FLAP ACTUATOR MOTOR
2 2767 20GY/YL POTENTIOMETER-AIR DISTRIBUTION FLAP ACTUATOR MOTOR
3 2405 20RD/BK POTENTIOMETER-AIR DISTRIBUTION FLAP ACTUATOR MOTOR
4 2402 20GY/DG MOTOR-AIR DISTRIBUTION FLAP ACTUATOR MOTOR
5 2403 20DB/RD MOTOR-AIR DISTRIBUTION FLAP ACTUATOR MOTOR
