Washer Fluid Level Switch: Diagrams

Component ID: 616
Component : SWITCH-WASHER-FLUID LEVEL

Connector:
Name : SWITCH-WASHER-FLUID LEVEL
Color :
# of pins : 2




Pin Circuit Description
1 595 20BR/DG WASHER FLUID LEVEL SWITCH RETURN
2 596 20DB/WT WASHER FLUID LEVEL SWITCH SENSE
