Sensor-A/C Pressure-Roof

Component ID: 483
Component : SENSOR-A/C PRESSURE-ROOF

Connector:
Name : SENSOR-A/C PRESSURE-ROOF
Color :
# of pins : 3




Pin Circuit Description
1 3796 20BR/OR MINUS REFRIGERANT PRESSURE SENSOR
2 3795 20DG SIGNAL-REFRIGERANT PRESSURE SENSOR
3 3797 20DB/RD PLUS REFRIGERANT PRESSURE SENSOR
