Coolant Level Sensor: Diagrams

Component ID: 591
Component : SWITCH-COOLANT LEVEL

Connector:
Name : SWITCH-COOLANT LEVEL
Color :
# of pins : 2




Pin Circuit Description
1 591 20BR/YL COOLANT LEVEL SWITCH RETURN
2 594 20DG/YL COOLANT LEVEL SWITCH SENSE
