Rear

REAR





1. Reconnect the electrical connector (2) to the transponder (3).
2. Install the transponder (3) into the cover (1).




3. Install the transponder mounting bracket only if removed. Tighten the nuts to 3 Nm (25 in.lbs.).
4. Install the transponder with cover (3) to the body and install the mounting screws (1). Tighten the screws to 3 Nm (25 in.lbs.).
5. Lower the vehicle.
