Sensor-Obstruction-Power Sliding Door-Right

Component ID: 526
Component : SENSOR-OBSTRUCTION-POWER SLIDING DOOR-RIGHT

Connector:
Name : SENSOR-OBSTRUCTION-POWER SLIDING DOOR-RIGHT
Color :
# of pins : 2




Pin Circuit Description
1 U6104 18BR/DG GROUND
2 2594 20YL FRONT OBSTRUCTION SENSOR SIGNAL
