Sensor-Obstruction-Power Sliding Door-Left

Component ID: 525
Component : SENSOR-OBSTRUCTION-POWER SLIDING DOOR-LEFT

Connector:
Name : SENSOR-OBSTRUCTION-POWER SLIDING DOOR-LEFT
Color :
# of pins : 2




Pin Circuit Description
1 U6105 18BR/DB GROUND
2 2689 20YL FRONT OBSTRUCTION SENSOR SIGNAL
